H-Section Joiners
Join two sheets edge-to-edge — pick the joiner to match your sheet thickness.
from $49.98ex GST
Technical Specifications
| Material Type | Modified Acrylic (PMMA – High Impact) |
| Brand | Zenoplex |
| Density | 1.19 g/cm³ |
| Light Transmission (Clear) | Up to 90% |
| Tensile Strength | ~55–65 MPa |
| Flexural Strength | ~90 MPa |
| Impact Resistance | ~5–10× standard acrylic |
| Maximum Continuous Service Temp | ~80 °C |
| Water Absorption (24 hrs) | ~0.3% |
| UV Resistance | Excellent |
| Chemical Resistance | Good (avoid solvents) |
| Application | Machine guards, protective barriers, point-of-sale displays |
Certifications & Downloads
High Impact Acrylic Sheets
A premium high impact acrylic sheet with excellent light diffusion and durability. At 1500 × 4000mm, it is one of the only acrylic sheet available over 3 metres in length, making it ideal for…
$417.46 + GST
inc. GST $459.21
Thermoforming
Great for moulding
Perfect for Signage
Lightboxes
1 Configuration
Collect from our Gold Coast factory
9 Leda Drive, Burleigh Heads QLD 4220
Mon-Thu 7:30am-4pm, Fri 7:30am-3:30pm AEST
Pickup is from this Gold Coast site only.
2 Service add-ons
Optional finishing services - toggle any you need.
Drill holes
Optional. Add drilled holes to your piece.
Flame polished edges
Clear acrylic only - optical-grade edge finish
Pick which edges to polish.
Flame polish is only available on acrylic.
Rounded corners
Manual router - per-corner price scales with thickness
Edge profile
Rounded or 45 degree bevel - per-metre rate x thickness
A rounded edge can be at most half the sheet thickness.
Buy more, save more
Buy 5+ sheets save 5%
Buy 10+ sheets save 10%
5 · 5% 10 · 10%
$0.00 + GST
Pay
G Pay
| - - | - |
|---|---|
| Quantity | - |
| Drill holes | - |
| Flame polish | - |
| Rounded corners | - |
| Edge profile | - |
| Cutting & Setup Fee Charged once per order | - |
| Shipping | estimate above |
Australia-wide delivery Priced to your postcode
Precision Cut +/-0.5mm tolerance
Quality Assured Industry-leading
Why choose High Impact Acrylic Sheets?
ZENOPLEX® OPAL-25 IM50 – 1500 × 4000 × 4.5mm
Key Features
Applications
Frequently Asked Questions
Why Choose ZENOPLEX®
- High Impact Strength – Up to 10× more impact resistant than standard acrylic .
- Exclusive Size – 1500 × 4000mm, the only acrylic sheet available in lengths exceeding 3000mm.
- Opal-25 Finish – Excellent light diffusion with balanced brightness.
- Durable & Lightweight – Safer than glass and easy to cut, drill, and fabricate.
- UV Resistant – Suitable for both indoor and outdoor installations.
- Oversized illuminated signage & lightboxes
- Retail displays and exhibition panels
- Architectural glazing and partitions
- Decorative panels & interior features
- Fabrication projects requiring extra-large sheets
- Technical Details
High Impact Opal Acrylic Sheet – Extra Large Format
One of the only plastic acrylic sheets over 3 metres – built for big ideas.
ZENOPLEX® OPAL-25 IM50 is a premium high impact acrylic sheet designed for strength, light diffusion, and large-scale applications. At 1500 × 4000mm, it is the only sheet on the market extending well over 3050mm in length, giving designers and fabricators unmatched flexibility for oversized projects.
Product Code: ZENOPLEX® OPAL-25 IM50
Product Type: High Impact Acrylic
Colour/Finish: Opal White (25% light transmission)
Sheet Size: 1500 × 4000mm
Thickness: 4.5mm
Features: UV resistant, lightweight, high impact resistance, easy to machine
Q: Why is ZENOPLEX® OPAL-25 IM50 unique?
A: It is the only acrylic sheet available in lengths over 3000mm (this one is 4000mm), making it ideal for large signage, panels, and projects that can’t be achieved with standard sheet sizes.
Q: Can ZENOPLEX® OPAL-25 IM50 be used outdoors?
A: Yes, it is UV resistant and performs well in both indoor and outdoor applications without yellowing.
Q: How does high impact acrylic differ from standard acrylic?
A: High impact acrylic offers up to 10× the impact resistance, making it more durable and less prone to breakage while remaining lightweight and easy to fabricate.
Q: What is the light transmission of Opal-25?
A: Opal-25 provides around 25% light transmission, giving excellent diffusion for illuminated signage and lightbox applications.
Q: Can I cut or machine this sheet myself?
A: Yes. It can be cut, drilled, or CNC-routed using standard acrylic fabrication tools. For best results on such a large format sheet, professional handling is recommended.
ZENOPLEX® OPAL-25 IM50 combines durability, superior light diffusion, and extra-large sheet size - giving fabricators and designers a product that no other supplier can match.
Ready to order your High Impact Acrylic Sheets?
Cut to size, precision finished and dispatched Australia-wide. Not sure which material suits your job? We'll help you choose the right one.
Frequently purchased with
Related Products
Technical Specifications
| Material Type | Modified Acrylic (PMMA – High Impact) |
| Brand | Zenoplex |
| Density | 1.19 g/cm³ |
| Light Transmission (Clear) | Up to 90% |
| Tensile Strength | ~55–65 MPa |
| Flexural Strength | ~90 MPa |
| Impact Resistance | ~5–10× standard acrylic |
| Maximum Continuous Service Temp | ~80 °C |
| Water Absorption (24 hrs) | ~0.3% |
| UV Resistance | Excellent |
| Chemical Resistance | Good (avoid solvents) |
| Application | Machine guards, protective barriers, point-of-sale displays |
Certifications & Downloads
Need this custom cut or fabricated?
Send us your drawing (DXF, DWG, PDF, EPS, STEP) and we'll quote your High Impact Acrylic Sheets to spec.
